| SPECIFICATION / MODELS |
UNIT |
DOUBLE COLUMN CNC SURFACE GRINDING MACHINE |
| C2 X 4080 |
C2 x 6080 |
C2 X 60100 |
C2 X 60120 |
C2 X 80200 |
| GENERAL CAPACITY |
| Grinding surface of table |
mm |
1000×2000 |
1500×2000 |
1500×2500 |
1500×3000 |
2000×5000 |
| Max. travel (cross x longitudinal) |
mm |
1100×2200 |
1600×2200 |
1200×2700 |
1600×3200 |
2100×5200 |
| Wheel bottom to table |
mm |
600 |
| (Vertical Head) |
| Spindle center height from table |
mm |
850 |
| Max. height from table top to bottom of standard wheel |
mm |
500 |
| Hydraulic table speed |
m/min |
1.5 – 18 TO 2.5 / 25 (Optional) |
| CROSS MOVEMENT |
| Clearance between the columns |
mm |
1200 |
1700 |
2200 |
| Intermittent cross feed-approx.(Electro-mechanical) |
mm |
1-40 |
| Rapid traverse approx. |
mm/min |
3000 |
| Hand feed per division MPG |
mm |
0.001 |
| VERTICAL DOWNFEED |
| Rapid traverse approx. |
mm/min |
3000 |
| Hand feed per division MPG |
mm |
0.001 |
| GRINDING WHEEL |
| Dimension(O.D x W x I.D) |
mm |
510x100x203 |
| Spindle speed(50/60Hz) |
RPM |
1000 to 1400 |
| MOTOR |
|
| Horizontal head spindle motor |
HP |
15 / 20 |
| Vertical head spindle motor |
HP |
7.5 / 10 |
| CNC SPECIFICATION |
| Crossfeed rapid feedrate(approx.) |
mm/min |
3000 |
| Cross/Vertical infeed least input increment |
mm |
0.001 |
| Rapid vertical rate |
mm/min |
3000 |
